Wet Well, Intake Well & Pump House Construction Contractor in India

The execution of massive municipal and industrial water supply schemes requires highly specialized civil, structural, and hydraulic engineering capabilities. At the heart of these bulk water transmission schemes lie water intake systems, wet wells, and raw/clear water pump houses. These critical installations must be designed to withstand severe hydrogeological pressures, scouring, seismic forces, and chemical exposure for a design life typically exceeding 50 to 100 years.

As a premier, vertically integrated Engineering, Procurement, and Construction (EPC) company, JND INFRASTEEL PRIVATE LIMITED ([www.jndinfrasteel.com](https://www.jndinfrasteel.com)) stands at the forefront of this sector. Specializing in high-capacity pump house construction, large-diameter Mild Steel (MS) pipeline fabrication, and complex concrete substructures, JND InfraSteel delivers turnkey solutions across Gujarat, pan-India, and global markets.

---

Table of Contents

1. [Introduction to Municipal and Industrial Water Intake Infrastructure](#1-introduction-to-municipal-and-industrial-water-intake-infrastructure) 2. [Structural Design Framework: Deciphering IS 456 and IS 3370](#2-structural-design-framework-deciphering-is-456-and-is-3370) 3. [Hydrogeological and Geotechnical Engineering for Intake Wells](#3-hydrogeological-and-geotechnical-engineering-for-intake-wells) 4. [Step-by-Step Construction Methodology: Intake Well to Pump House](#4-step-by-step-construction-methodology-intake-well-to-pump-house) 5. [Technical Parameter Matrix: Intake & Pump House Design Parameters](#5-technical-parameter-matrix-intake-pump-house-design-parameters) 6. [Electro-Mechanical and Piping Integration: The JND Advantage](#6-electro-mechanical-and-piping-integration-the-jnd-advantage) 7. [Quality Control Gates, Testing Protocol, and Quality Assurance](#7-quality-control-gates-testing-protocol-and-quality-assurance) 8. [Turnkey Engineering Procurement & Construction (EPC) by JND InfraSteel](#8-turnkey-engineering-procurement--construction-epc-by-jnd-infrasteel) 9. [Conclusion & Call to Action](#9-conclusion--call-to-action) 10. [Frequently Asked Questions (FAQs)](#10-frequently-asked-questions-faqs)

---

1. Introduction to Municipal and Industrial Water Intake Infrastructure

In bulk water resource planning, the intake structure is the initial gateway through which raw water is drawn from rivers, reservoirs, canals, or oceans. Whether it is a run-of-the-river intake in the Narmada or Tapi basins of Gujarat, or a marine intake system along the Indian coastline, the structure must operate reliably under extreme fluctuations in water levels (from Lowest Water Level - LWL, to High Flood Level - HFL).

```
+--------------------------------------------------------+
| RIVER / RESERVOIR |
+---------------------------+----------------------------+
| (Inflow via Trash Racks/Gravity Mains)
v
+--------------------------------------------------------+
| INTAKE WELL & SCREEN CHAMBER (Submerged) |
+---------------------------+----------------------------+
|
| (Gravity Conduits / Raw Water Mains)
v
+--------------------------------------------------------+
| WET WELL / SUMP (Pump Suction Sump) |
+---------------------------+----------------------------+
|
| (Vertical Turbine / Horizontal Split Case Pumps)
v
+--------------------------------------------------------+
| PUMP HOUSE SUPERSTRUCTURE (Dry Well) |
+---------------------------+----------------------------+
|
v (Bulk Water Transmission Mains)
```

The downstream component, the wet well, serves as a storage sump where water is balanced and prepared for high-pressure pumping. Directly integrated with or adjacent to the wet well is the pump house. Pump house construction encompasses a multi-disciplinary approach involving:

  • Geotechnical engineering (to prevent uplift and sinking tilts)

  • Structural engineering (conforming to IS 3370 and IS 456 standards)

  • Hydraulic engineering (to prevent vortex formation and air entrainment)

  • Mechanical engineering (integrating high-capacity pumps, valves, and headers)
  • JND InfraSteel executes these works on a turnkey basis, ensuring that civil structures are perfectly coordinated with custom-welded piping systems, including large-diameter MS lines, through our comprehensive [[services](/services)/civil-construction] and [[services](/services)/pipeline-infrastructure] divisions.

    ---

    2. Structural Design Framework: Deciphering IS 456 and IS 3370

    Liquid-retaining concrete structures require design considerations far beyond those of typical high-rise buildings. The primary structural design of intake wells and wet wells in India is governed strictly by IS 3370 (Parts 1 to 4): Code of Practice for Concrete Structures for Storage of Liquids and IS 456: Code of Practice for Plain and Reinforced Concrete.

    ```
    +------------------------+
    | IS 3370 & IS 456 |
    | Structural Design |
    +-----------+------------+
    |
    +----------------------+----------------------+
    v v
    +--------------------+ +--------------------+
    | Limit State of | | Limit State of |
    | Strength | | Serviceability |
    | (Structure Load | | (Crack Width |
    | Carrying Capacity) | | Control <= 0.2mm) |
    +--------------------+ +--------------------+
    ```

    Crack Width Control and Limit State of Serviceability

    Under IS 3370 (Part 2), liquid-retaining structures must be designed to restrict the surface crack width to a maximum of 0.2 mm for normal exposure, and in highly aggressive or saline environments (such as coastal areas of Gujarat), down to 0.1 mm. This is achieved by limiting the allowable tensile stress in the steel reinforcement and checking the concrete for direct and flexural tension under working loads.

    Under the Limit State of Serviceability, the direct tensile stress in steel ($\sigma_{st}$) is typically restricted to:

  • 130 MPa for Mild Steel bars (Grade I of IS 432).

  • 130 MPa to 150 MPa for deformed Fe 415/Fe 500 bars depending on the proximity to the liquid-retaining face.
  • By utilizing advanced finite element analysis (FEA) software, JND InfraSteel’s engineering team designs concrete cross-sections that balance reinforcement density with optimum concrete thickness, preventing the thermal and shrinkage cracking common in mass concrete placements.

    Concrete Grades, Aggregates, and Water-Cement Ratio

    For water-retaining components (steining of intake wells, bottom plugs, and wet well walls), the minimum concrete grade specified under IS 3370 is M30. However, for deep well structures subjected to aggressive soil chemistry or heavy dynamic loads from vertical turbine pumps, JND InfraSteel standardizes on M35 or M40 concrete grades.

    The key mix design parameters enforced during our construction projects include:

  • Maximum Water-Cement (w/c) Ratio: Limited strictly to 0.40 to 0.45 to ensure low permeability.

  • Minimum Cement Content: Configured at 320 kg/m³ to 360 kg/m³ of concrete to guarantee dense structural matrices while avoiding excess hydration heat.

  • Mineral Admixtures: Integration of Fly Ash (conforming to IS 3812) or Ground Granulated Blast-furnace Slag (GGBS as per IS 12089) to enhance durability against sulfate and chloride attacks.
  • Design of Dry Wells and Superstructures (IS 456)

    While the liquid-retaining sections adhere to IS 3370, the dry well, electric panels rooms, and pump house superstructure are designed under IS 456. The transition zones—where wet wells contact dry wells—are critical structural interfaces. JND InfraSteel designs heavy shear keys and water stops (typically PVC or hydrophilic swellable water bars) to prevent water migration across these dry-wet interfaces.

    ---

    3. Hydrogeological and Geotechnical Engineering for Intake Wells

    Developing an intake well in a riverbed or deep reservoir requires extensive geotechnical evaluation. The construction methodology must account for deep alluvial or rocky strata, high water tables, and scouring during monsoon seasons.

    Open Caisson / Well Sinking Method (Coub/Steining)

    For large-diameter wet wells and intake wells in riverbeds, the open caisson (well-sinking) method is the most reliable approach. The structure is cast in lifts on the surface and sunk progressively into the ground by excavating soil from within the well cavity.

    The mechanical equilibrium during well sinking is governed by the following formula:

    $W > F_s + R_b$

    Where:

  • $W$ = Total weight of the concrete steining and any added kentledge (temporary weights).

  • $F_s$ = Skin friction between the outer surface of the concrete steining and the surrounding soil.

  • $R_b$ = Base resistance offered by the soil at the cutting edge.
  • ```
    | |
    |====[ CONCRETE STEINING ]======|
    | |
    | / \ | <-- Skin Friction (Fs)
    Soil / Silt | | | |
    =============\ | | DREDGING WELL | | /=============
    \ | | (Soil Removal) | | / Water Table
    \| | | |/
    \ | | /
    \ | |/
    \ | |
    \|_ _|
    \ \ / /
    \ \ / / <-- Base Resistance (Rb)
    \_| |_/
    \ CUTTING EDGE /
    \______________/
    ```

    JND InfraSteel's engineering team calculates the required steining thickness based on this balance. If the skin friction is underestimated, the well will "hang" (cease to sink). To mitigate this, we inject bentonite slurries around the outer periphery through pre-installed piping to act as a lubricant, reducing the skin friction coefficient.

    Active/Passive Earth Pressures and Uplift (Buoyancy)

    Deep wet wells must be designed to resist lateral earth pressures (calculated using Rankine’s or Coulomb’s earth pressure theories) and hydrostatic uplift when the well is completely empty for maintenance.

    To prevent hydrostatic flotation (buoyancy), the safety factor ($F.S.$) against uplift must be checked:

    $F.S. = \frac{W_D + W_F + P_{f}}{U_{max}} \ge 1.25$

    Where:

  • $W_D$ = Dead weight of the concrete structure (plug, slab, walls, columns).

  • $W_F$ = Weight of backfill resting on projecting concrete flanges (if provided).

  • $P_{f}$ = Skin friction developed along the outer face of the walls.

  • $U_{max}$ = Maximum uplift force calculated based on the highest recorded groundwater table.
  • If the structural weight is insufficient to counteract the buoyancy force, JND InfraSteel implements specialized engineering solutions, such as installing tension anchors into the bedrock or casting a thick, extended raft slab (heel projection) to engage the weight of the surrounding backfill soil.

    ---

    4. Step-by-Step Construction Methodology: Intake Well to Pump House

    The successful delivery of a turnkey intake well and pump house construction project involves a series of sequential civil and structural phases. Any deviation in the execution sequence can lead to structural distress, well tilts, or water ingress.

    ```
    +-------------------------------------------------------------+
    | Phase 1: Soil Investigation, Bathymetric Surveys, Design |
    +------------------------------+------------------------------+
    |
    v
    +-------------------------------------------------------------+
    | Phase 2: Steel Cutting Edge Assembly & Well Curb Casting |
    +------------------------------+------------------------------+
    |
    v
    +-------------------------------------------------------------+
    | Phase 3: Steining Cast Lifts (M30/M35) & Sinking Operations |
    +------------------------------+------------------------------+
    |
    v
    +-------------------------------------------------------------+
    | Phase 4: Tremie Bottom Plugging & Sand/Concrete Filling |
    +------------------------------+------------------------------+
    |
    v
    +-------------------------------------------------------------+
    | Phase 5: Wet Well Substructure Slab & Superstructure Works |
    +-------------------------------------------------------------+
    ```

    Phase 1: Site Mobilization & Geotechnical Investigation

    Before starting, detailed bathymetric surveys, geo-exploration (standard penetration tests - SPT, and core drilling), and hydrological studies are conducted. This establishes the exact scour depth, rock level, and safe bearing capacity of the soil.

    Phase 2: Fabrication of Cutting Edge & Casting of Well Curb

    The cutting edge—made of heavy structural steel angles and plates (typically Fe 250 or Fe 350 grade conforming to IS 2062)—is assembled on-site. 1. Positioning: The cutting edge is perfectly leveled on the prepared sand bed or riverbed. 2. Curb Reinforcement: The concrete well curb, designed with a heavy wedge-shaped cross-section, is reinforced and cast using M35 concrete. 3. Curing: The curb is water-cured for a minimum of 7 days to reach design strength before any sinking stress is applied.

    Phase 3: Steining Casting and Well Sinking

    The well steining (the vertical concrete wall) is cast in progressive vertical lifts of 2.0 m to 2.5 m.
  • Excavation Process: Soil within the well is excavated using heavy mechanical grab buckets operated from crawler cranes.
  • Controlled Sinking: As soil is excavated, the well sinks under its own weight. JND's survey teams continuously monitor verticality using twin-directional plumb bobs and total station instruments to catch any tilts early.
  • Correction of Tilts: If tilting occurs, JND applies corrective measures:
  • * Eccentric dredging (excavating more soil on the higher side). * Appending eccentric kentledge loads. * Using water-jetting or air-lifting nozzles on the higher side to reduce skin friction.

    Phase 4: Bottom Plugging (Underwater Concreting)

    Once the well reaches its final foundation level (the founding stratum), the bottom must be sealed to prevent water ingress from the base.
  • Methodology: This is achieved through tremie concreting under water. A continuous pour of highly cohesive self-compacting concrete (minimum M30 grade, using a mix containing high cementitious content and plasticizers) is pumped through a submerged tremie pipe.
  • Sealing: The tremie pipe remains submerged in the freshly placed concrete to prevent wash-out of cement. The bottom plug is allowed to cure under undisturbed water conditions for at least 10 to 14 days.
  • Phase 5: Dewatering, Backfilling, and Top Slab Construction

    After curing, the well is dewatered. JND's engineering teams inspect the plug to ensure there is no leakage.
  • Filling: Sand or concrete filling is placed above the bottom plug to provide stability and load distribution.
  • Top Plug / Raft Slab: A reinforced concrete top slab (raft) is cast over the filling. This slab forms the foundation for the pump columns, screens, and internal wet well partition walls.
  • Superstructure: The dry well, structural columns, crane gantry beams (for EOT/HOT cranes), and the pump house roof slab are constructed to finalize the civil works.
  • ---

    5. Technical Parameter Matrix: Intake & Pump House Design Parameters

    The table below outlines JND InfraSteel’s standard engineering configurations and design envelopes for municipal and industrial pump house projects:

    | Parameter Component | Structural Specification | Applicable Codes | Engineering/Quality Gate |
    | :--- | :--- | :--- | :--- |
    | Concrete Grade | M30 to M45 (Self-Compacting Concrete for Plugs) | IS 456 / IS 3370 | 28-day Compressive Strength Testing (Cube & Core) |
    | Reinforcement Steel | TMT Fe 500D / Fe 550D (Corrosion Resistant - CRS) | IS 1786 | Ultimate Tensile Strength & Elongation Tests |
    | Max Crack Width Limit | 0.2 mm (Standard), 0.1 mm (Highly Corrosive Environment) | IS 3370 Part 2 | Finite Element Crack Width Evaluation |
    | Sinking Tilt Tolerances | Limit of 1 in 80 (Verticality) | IRC:78 / IS 11116 | Continuous Total Station & Plumb Alignment |
    | Water Stop Profiles | PVC Centerbulb / Hydrophilic Ribbed Waterstops | IS 12200 / IS 15058 | Visual Inspection & Pressure Grouting Checks |
    | Intake Pipe Connection | Submerged Arc Welded (SAW) / ERW MS Line | IS 3589 / API 5L | NDT - Radiography, Ultrasonic, and Hydro-test |
    | Structural Steel (Cranes) | Fe 250 / Fe 350 / E250 | IS 2062 | Load Deflection Verification (HOT/EOT Crane Runs) |
    | Epoxy Coating System | Food-grade Epoxy (for potable water) | IS 14582 | DFT (Dry Film Thickness) gauge measurements |

    ---

    6. Electro-Mechanical and Piping Integration: The JND Advantage

    A major bottleneck for many civil contractors is the complex interface between concrete civil structures and heavy-duty steel piping systems. JND InfraSteel eliminates this risk through our core in-house capability in high-end steel piping, utilizing advanced welding systems and high-grade materials.

    ```
    +-------------------------------------------------+
    | INTAKE WELL / WET WELL WALL |
    +-----------------------+-------------------------+
    |
    [Puddle Flange Cast Integrity]
    |
    v
    +-------------------------------------------------+
    | IS 2062 / API 5L MS PIPING |
    | (Corrosion Protection: Epoxy / Polyurethane) |
    +-----------------------+-------------------------+
    |
    [Field Jointing: Manual Metal Arc / SMAW]
    |
    v
    +-------------------------------------------------+
    | IS 3370 COMPLIANT WATER-TIGHT INTERFACE |
    +-------------------------------------------------+
    ```

    High-Diameter MS Pipe Fabrication and Jointing

    Our fabrication yards manufacture large-diameter Submerged Arc Welded (SAW) pipes conforming to IS 3589, API 5L, and BS EN 10224 standards. Learn more about our manufacturing specifications through our [[products](/products)/ms-saw-3.1] and [[products](/products)/ms-erw-1.1] product lines.

    When routing water suction and discharge headers through concrete wet well walls, JND fabricates custom puddle flanges. These structural steel components are welded directly onto the outer wall of the MS pipe and cast within the concrete wall of the wet well. The puddle flange:

  • Prevents water from migrating along the outer surface of the pipe.

  • Anchors the piping against heavy hydraulic thrust loads during pump startup and shutdown.
  • Welding Technologies and Quality Assurance

    All field jointing of steel pipelines, manifolds, and bends is performed by certified structural welders using manual metal arc welding (SMAW) or semi-automatic gas metal arc welding (GMAW) procedures. Welds conform to IS 5822 (Code of practice for laying of welded steel pipes for water supply) and API 1104.
  • Non-Destructive Testing (NDT): 100% visual inspection is coupled with Radiographic Testing (RT) or Ultrasonic Testing (UT) of critical joints, especially those embedded in concrete or beneath riverbeds.
  • Corrosion Mitigation: Piping is protected inside and out with high-performance anti-corrosive coatings, including liquid epoxy linings conforming to AWWA C210 or polyurethane (PU) coatings as per AWWA C222.
  • ---

    7. Quality Control Gates, Testing Protocol, and Quality Assurance

    To ensure structural durability and hydraulic integrity, JND InfraSteel establishes precise quality control (QC) gates at every step of project execution.

    ```
    [QC Gate 1: Material Inflow] -> Concrete Mix (M35/M40), Reinforcement (Fe 500D), Steel Plates
    |
    v
    [QC Gate 2: Fabrication] -> Steel Curb Fabrication, Weld NDT (Radiography/UT)
    |
    v
    [QC Gate 3: Concrete Pour] -> Temperature Checks, Slump Flow, Cylinder Compressive Tests
    |
    v
    [QC Gate 4: Hydraulic Test] -> IS 3370 Part 1 Water Tightness Test (7-Day Permissible Drop)
    |
    v
    [Final Handover & Commissioning]
    ```

    Water Tightness Testing (IS 3370 Part 1)

    Upon completing concrete curing, and prior to any external backfilling or internal epoxy painting, the wet well is subjected to a hydrostatic water tightness test: 1. Filling: The structure is filled with water at a rate not exceeding 1.2 meters of depth per 24 hours to prevent sudden thermal or structural shock. 2. Stabilization: Once filled to the design supply level, the water is allowed to stand for 7 days to satisfy structural absorption. 3. Measurement: A high-precision hook gauge measures the drop in water level over the next 24 hours. 4. Acceptance Criteria: Under IS 3370, the maximum permissible drop in water level over 24 hours, after accounting for surface evaporation, is 20 mm or 0.1% of the total water volume, whichever is less. Any visible weeping or dampness on the dry outer face of the walls is treated as a defect and repaired using high-pressure polyurethane or epoxy grouting.

    Concrete Cover and Reinforcement Inspection

    To prevent corrosion of steel reinforcement inside the water storage environment, a clear concrete cover must be strictly maintained:
  • Minimum Concrete Cover: Standardized at 45 mm to 50 mm on the liquid-retaining faces.
  • Cover Blocks: JND utilizes heavy-duty, high-density polymer-concrete cover blocks of matching concrete grade to ensure reinforcement does not shift during concrete pumping and mechanical vibration.
  • ---

    8. Turnkey Engineering Procurement & Construction (EPC) by JND InfraSteel

    Executing complex infrastructure projects requires an EPC partner who can coordinate civil excavation, heavy structural concreting, mechanical assembly, and pipeline commissioning.

    ```
    +-------------------------------------------------+
    | JND INFRASTEEL EPC CONTRACTS |
    +-----------------------+-------------------------+
    |
    +----------------------+----------------------+
    | |
    v v
    [Engineering & Design] [Fabrication & Execution]
    - Bathymetric Modeling - In-house SAW/ERW Pipes
    - IS 3370 Concrete Design - Heavy Machined Steel Curbs
    - Hydraulic Transient Analysis - Complex Sinking Operations
    ```

    Integrated Engineering Solutions

    At JND InfraSteel, our turnkey capability bridges the gap between civil execution and mechanical integration. We deliver:
  • Comprehensive hydraulic transient (water hammer) analysis for the pump discharge lines.
  • Complete surge protection systems, including air vessels, surge anticipation valves, and bypass lines.
  • In-house design of intake screens (passive wedge-wire or mechanical traveling water screens) to protect high-value pumping systems.
  • Geographic Reach: Gujarat to Global Markets

    With our corporate roots and extensive steel stockyard footprint in Gujarat, JND InfraSteel has completed complex municipal and industrial projects across diverse geographic regions:
  • Gujarat (P1 Focus): Serving major municipal corporations, smart cities, and industrial clusters (DAHEJ, GIFT City, Sanand, Mundra) with water supply and desalination intake infrastructure.
  • Pan-India (P2 Focus): Deploying specialized engineering teams across various states for river diversion projects, irrigation pump houses, and urban water grid projects.
  • Global / International (P3 Focus): Exporting high-performance fabricated steel pipelines, customized puddle flanges, structural steel gantries, and engineering services globally.
  • ---

    9. Conclusion & Call to Action

    The construction of intake wells, wet wells, and municipal pump houses is a highly complex engineering endeavor. Success relies on strict adherence to structural codes (IS 3370 / IS 456), precise control during geotechnical well sinking, and flawless integration of high-pressure steel pipelines. Partnering with a specialized EPC firm like JND InfraSteel ensures that these multi-disciplinary systems are designed and constructed to operate reliably for decades.

    Partner with India's Premier Water Infrastructure Engineers

    For your upcoming municipal water supply schemes, industrial raw water intake networks, or large-diameter bulk water transmission mains, trust the expertise of JND INFRASTEEL PRIVATE LIMITED.
  • Explore our complete civil contracting capabilities: [[services](/services)/civil-construction]
  • Review our large-scale transmission main projects: [[services](/services)/pipeline-infrastructure]
  • Browse our steel piping and manufacturing portfolio: [[products](/products)]
  • Read technical insights on water infrastructure: [/blog]
  • Contact our Engineering Desk today:

  • Email: info@jndinfrasteel.com / sales@jndinfrasteel.com

  • Website: [www.jndinfrasteel.com](https://www.jndinfrasteel.com)
  • ---

    10. Frequently Asked Questions (FAQs)

    FAQ 1. What are the key differences between designing water-retaining structures under IS 3370 versus IS 456?

    IS 456 is the general standard for reinforced concrete structures, focusing primarily on strength criteria (ultimate limit state). IS 3370 is a specialized code specifically for liquid storage structures, placing its primary focus on serviceability criteria—specifically, crack control and liquid tightness. Under IS 3370, concrete tensile stresses are strictly limited, minimum cement content is increased, maximum water-cement ratio is reduced, and permissible steel tensile stresses are kept much lower than under IS 456. This prevents the formation of micro-cracks that could lead to structural leakage or corrosion of embedded reinforcement.

    FAQ 2. How does JND InfraSteel mitigate the risk of tilts and shifts during well-sinking in alluvial river beds?

    JND InfraSteel employs a rigorous, real-time monitoring and correction protocol during the excavation phase. We position twin-directional plumb-bobs and use high-precision electronic total stations to check the verticality of the steining after every 500 mm of sinking. If a tilt exceeds 1 in 100, we apply immediate corrective interventions. These include:
  • Eccentric Dredging: Excavating soil specifically from the higher side of the well.
  • Kentledge Loading: Applying heavy, asymmetric concrete blocks to the higher edge of the steining.
  • Water Jetting: Injecting pressurized water through pre-installed pipes on the higher side to reduce soil skin friction, allowing that side to sink and level the well.
  • FAQ 3. What underwater concreting techniques are employed for the bottom plug of an intake well?

    To seal the bottom of an intake well beneath the water table, we execute tremie concreting. This process utilizes a continuous steel pipe (the tremie) with a hopper at the top. The pipe is lowered to the bottom of the well, and a highly cohesive, self-compacting concrete mix (containing concrete plasticizers and a high cement content of over 400 kg/m³) is poured into it.

    The tremie pipe is kept submerged within the newly deposited concrete mass to prevent contact with the surrounding water, which avoids cement wash-out. The concrete spreads out from the bottom of the pipe, displacing the water upward and creating a dense, watertight concrete seal.

    FAQ 4. Can JND InfraSteel handle the design and execution of bulk transmission lines connecting to the pump house?

    Yes. JND InfraSteel is a fully integrated EPC company. Beyond our civil engineering capabilities for pump house construction, we operate our own large-scale steel pipe fabrication yards. We manufacture, weld, lay, and commission large-diameter Mild Steel (MS) Submerged Arc Welded (SAW) and ERW pipes. This allows us to deliver a complete, seamless system—from the intake well to the wet well via gravity mains, and out through the high-pressure pumping manifolds directly into the bulk water transmission network.

    FAQ 5. How is water tightness tested in large-scale wet wells prior to commissioning?

    We perform hydrostatic testing in accordance with IS 3370 Part 1. Once the concrete has fully cured and before any external soil backfilling or interior epoxy coating is applied, the wet well is filled slowly with water at a maximum rate of 1.2 meters of depth per 24 hours. The water is left to stand for 7 days to allow for absorption into the concrete.

    We then measure the water level over the next 24 hours using a highly precise hook gauge. The test is successful if the total water level drop over 24 hours (excluding surface evaporation) is less than 20 mm or 0.1% of the total volume, and there is no visible weeping or dampness on the exterior concrete walls.

    Related Infrastructure Solutions

    To learn more about JND InfraSteel's engineering services, check out our structural capabilities:
  • [Turnkey Pipeline Infrastructure Solutions](/services/pipeline-infrastructure) - Large diameter water grids, hydrostatic testing, and EPC contracting.
  • [Heavy Civil Construction Works](/services/civil-construction) - Reinforced concrete reservoirs, pump houses, and intakes well.
  • [Steel Material Trading & Stockyards](/services/stockyard-management) - High strength MS plates, coils, and hollow sections.
